Features:
8 coil stator magneto commonly used on 4-stroke 50cc, 125cc and 150cc GY6 scooter engines. Also sometimes referred to as a stator comp.
100% New REAL COPPER stator magneto 8 pole work with gy6 engine 50cc scooter, moped, Atv, go kart, buggy.
For GY6 125cc 150cc GY6 ATV Quad Dirt bike Scooter
High quality real copper guaranty, not the fake copper low quality one.
Specifications??
8 pole
Diameter 88mm
Center inner diameter: 29mm
Bolt Hole Spacing: 41mm
Connections: 3 wires female plug & 2 single female wires
Wire length: 330mm (13 in)
DC Current
Mechanics Note:
8 pole stator will work on any GY6 50cc 139QMB (and many others like 2-strokes) as long as you have a matching 8 pole flywheel rotor to go with it and have 4/5 wires. When you order a stator generator, be sure it matches the number of poles your rotor was made for. And in reverse, if you order a flywheel rotor, be sure it matches the number of poles on your stator. If you need both, order a matching 8 pole stator generator and flywheel rotor. This is AC Current Coil or DC so be sure it fits your engines electrical system.
—-Mortch Motor parts supported the Brands of—-
BAOTIAN, BASHAN, BENZHOU, CFMOTOR, CHARMING, DAYANG,
DINLI, FUXIN, GEELY, GILERA, HANGLONG, HAOJIN, HAOJUE, HISUN,
HONGZHOU, HUATIAN, JIAJUE, JIANSHE, JINLUN, JMSTAR, JONWAY,
KAITONG, KEEWAY, KINROAD, KYMCO, LIFAN, LINGBEN, LINGTIAN,
LINHAI, LINTEX, LONCIN, LONGJIA, MAWI, MEIDUO, MOTORRO,
PIAGGIO, QINGQI, RHON, RIEJU, SACHS, SHINERAY, SKYGO, SUKIDA,
TAOTAO, VESPA, VONROAD, WANGYE, WONJAN, XINGYUE, XINLING,
XINTIAN, YIBEN, YINGANG, ZHONGYU, ZNEN, ZONGSHEN, etc.
Note:
Please Please make sure this parts fits your particular model.
Many bikes have the same name but use different parts depending on the year of manufacture.
Package Include:
1x 8 coil stator magneto (As shown in pictures)
