Rebuilt H4 Magneto for Farmall A, B, C, H, M, W4, W6 Tractors – Includes Written Warranty

This is used on gas engine models: A, AV, B, BN, C, H, HV, Super HV, I4, I6, I9, M, MV, O, O4, O6, W4, W6, and Super A, AV, C, H, HV, M, MV, MTA

All magnetos were completely disassembled.
All parts were cleaned and inspected.
Bearings were cleaned, inspected, and packed with lube.
New coil was installed if old failed testing.
New points, and condenser were installed.
Front impulse coupler was cleaned, inspected, lubed and installed
Rotor was cleaned, inspected, and installed or replaced if needed.
Coil cover and distributor cap were cleaned, inspected, and painted, or replaced with new if defective.
Was assembled with new gaskets.
Was test run on bench.
Impulse works properly, and sparks 5/16″ at minimum-at cranking speed consistently.
At run speed spark jumps minimum of 5/16″” consistently, and run timing was checked at 35 degrees as the book specifies for this model magneto.

Magneto will come with one year written warranty, and also a mount gasket not pictured.
