Description
1 x SurTrack – Front Left CV Axle Shaft
1 x SurTrack – Front Right CV Axle Shaft
Abs Tone Ring Included: (Front Left CV Axle Shaft) No
Abs Tone Ring Included:(Front Right CV Axle Shaft) No
Axle Nut Head Type:(Front Left CV Axle Shaft)Hex
Axle Nut Head Type:(Front Right CV Axle Shaft)Hex
Axle Nut Height (in):(Front Left CV Axle Shaft) 6/7
Axle Nut Height (in):(Front Right CV Axle Shaft)6/7
Axle Nut Height (mm): (Front Left CV Axle Shaft) 21.5
Axle Nut Height (mm): (Front Right CV Axle Shaft) 21.5
Axle Nut Hex Size (in):(Front Left CV Axle Shaft)1 1/6
Axle Nut Hex Size (in): (Front Right CV Axle Shaft)1 1/6
Axle Nut Hex Size (mm):(Front Left CV Axle Shaft) 30
Axle Nut Hex size (mm): (Front Right CV Axle Shaft) 30
Axle Nut Included:(Front Left CV Axle Shaft) Yes
Axle Nut Included:(Front Right CV Axle Shaft) Yes
Axle Nut Length (in): (Front Left CV Axle Shaft)1 1/3
Axle Nut Length (in): (Front Right CV Axle Shaft) 1 1/3
Axle Nut Length (mm): (Front Left CV Axle Shaft) 34.6
Axle Nut Length (mm): (Front Right CV Axle Shaft) 34.6
Axle Nut Locking Type: (Front Left CV Axle Shaft)Stake
Axle Nut Locking Type:(Front Right CV Axle Shaft)Stake
Axle Nut Thread Size: (Front Left CV Axle Shaft)M22*1.5
Axle Nut Thread Size:(Front Right CV Axle Shaft)M22*1.5
Boot Material:(Front Left CV Axle Shaft)Neoprene
Boot Material: (Front Right CV Axle Shaft) Neoprene
Inboard Joint Type: (Front Left CV Axle Shaft) Male
lnboard Joint Type:(Front Right CV Axle Shaft) Male
lnboard Shaft Connection Style:(Front Left CV Axle Shaft)Male
Inboard Shaft Connection Style: (Front Right CV Axle Shaft) Male
New Or Remanufactured:(Front Left CV Axle Shaft) New
New Or Remanufactured:(Front Right CV Axle Shaft) New
Number of Inboard Splines: (Front Left CV Axle Shaft) 23
Number of Inboard splines: (Front Right CV Axle Shaft) 23
Number Of Outboard Splines: (Front Left CV Axle Shaft) 26
Number Of Outboard Splines: (Front Right CV Axle Shaft) 26
Outboard Joint Type: (Front Left CV Axle Shaft) Conventiona
loutboard Joint Type:(Front Right CV Axle Shaft) Conventional
outboard Shaft Connection style: (Front Left CV Axle Shaft)Conventional
Outboard Shaft Connection Style: (Front Right CV Axle Shaft)Conventional
overall Compressed Length (in):(Front Left CV Axle Shaft) 25.71
overall Compressed Length (in):(Front Right CV Axle Shaft) 35.24
overall Compressed Length (mm):(Front Left CV Axle Shaft)653
overall Compressed Length (mm): (Front Right CV Axle Shaft)895
