5 Functions in 1
Turn Left & Turn Right (Bright Amber)
Running Light (Low Red)
Braking Light(High Red)
License Plate Light(White)
Specification:
Power: 30W
LEDs quantity??5W*6
Color temperature: 6500K-7000K
Voltage??12V-30V DC
Lumens??2000LM*2
Size??4″
Bezel Color:Black
Lens Color: Red
Waterproof??IP-67
Working temperature??-40+85??C
Life time??50000+Hours
Material: ABS Plastic
LED Quantity: 60LEDs
Function(Lighting Color): Brake/ Running Light(Red),Turn Signal(Yellow, Left and Right), License Plate Light(White)
Features
All in One Led Tail Light(LED Tail Light with running light/brake light/Turn Signal Light)
License Plate Light (Lights up nice and bright and includes a clear lens to illuminate your license plate on the incorporated plate bracket.)
Lay Down Style (Lay down style, which is angled to follow the curve of your stock fender for the customized look.)
Wire Connection:
Black Wire——Negative
White Wire—–Running
Red Wire——-Brake Light
Yellow Wire—-Turn Right
Blue Wire——-Turn Left
—-Upgraded the connector, according to wire diagram, insert the wire to corresponding hole, directly plug in which get easier to install, but each model harness is different so we leave the wire end(running&brake) out of the plug for you, then you can insert them in the right position according to your model. Integrated turn signal lights, blue wire(turn left) and yellow wire(turn right) for you to connect according to your needs.
Note: The connector is not included.
Application:
1999-2006 Harley Sportster XL1200C Custom
2007-2010 Harley Sportster XL1200C Custom (EFI)
2000-2003 Harley Sportster XL 1200S sport
2004-2006 Harley Sportster XL883
2007-2008 Harley Sportster XL883(EFI)
2000-2006 Harley Sportster XL883C Custom
2011-2015 Harley Sportster XL883L Superlow
2002-2003 Harley Sportster XL883R
2005-2006 Harley Sportster XL883R
1999-2005 Harley Dyna Low Rider FXDL
2007-2008 Harley Dyna Street Bob FXDB
1999-2005 2007-2010 Harley Dyna Super Glide FXD
2012-2016 Harley Switchback FLD
2007-2013 Harley Electra Glide Classic FLHTC
2007-2016 Harley Softail Fat Boy FLSTF
2007-2008 Harley Touring Road Glide FLTR
2011-2013 Harley Touring Road Glide Ultra FLTRU
2007-2016 Harley Touring Road King FLHR
* It can not be installed on models with exclusive tail light such as XL 1200X, XL883N or Dyna wide glide,2007 Harley Davidson Sportster XL1200L.
Connector:
Please confirm the red wire(brake function) and white wire(running function) position
After confirm the position, then insert them in, and press the plug. Please double check red and white wire position before you insert them to the white plug of the taillight, because they can not be taken out from the plug once they are inserted into the white plug.
Integrated turn signal lights, using the yellow wire(turn right) blue wire(turn left) from the tail light, they can be connected to your current turn signals to add LED turn signal functions.
Note: Some old model it may need the resistor(package is not include) for turn signal if it is hyper flashing.
Package:
1 Piece of Low Profile Harley Davidson Led Tail Light
1 Piece of Gasket (prevent water infiltration)
