Technical Specification:
1. 30″ Rear Chase LED light bar with strobe lights
2. 30 LED(Color-RBYBR) including 6 Red LED – 6 Blue LED – 6 Amber LED – 6 Blue LED -6 Red LED
3. High intensity LED chip 50,000+ Hours life expectancy
4. Brake Light: this brake lights are wired independently, 2 blocks of 6 LEDs each
5.Turn Signal Light: this Turn Signal lights are wired independently, 2 blocks of 6 LEDs each
6.Reverse Light: this Reverse lights are wired independently, 1 block of 6 LEDs each
7.Strobe Light: red blue and amber strobe lights with independent wiring and flashing patterns that can be controlled by the on/off switch
8. it’s a must for All enthusiasts looking for extra safety.
Specification:
Type:30Inch Rear Front Chase LED Light bar
Light Length:30 inch
Bulb Type: LED
Color:Red Blue Amber
Input Voltage: DC 9-30V
LED QTY: 30/pcs
Luminous Flux: 30000LM
Beam: 121?? Flood Beam
Waterproof Rating: IP68
Lifespan: up to 50000 hours
Material: Die-cast Aluminum Housing, Toughed Glass Cover, aluminum substrate circuit board ,led chips,
Appearance: Black, Square Shape
Working Temperature: -60 to 85??
Dimension:31.8*5*1.6inch (Approx)
Weight:1.7KG / 3.74LB
Apply to car: front, rear, Rear Facing, Front Facing,
Accessories: mounting hardware set + wire harness with in-line dual switch + 3Pin extension cable + multifunction wire
Certification:CE, RoHs, FCC
Product Feature: Street-sport-motorcycles , Easy to install and use, Includes all necessary hardware needed, Durable and long lasting
Feature:
1. Strobe Lights have 8 Different Patterns
2. Independently Control Brake Light, Reverse Light, and Strobe Patterns, turn strobe off by holding
3. the strobe pattern switch for 3 seconds
4. Brighter and more effective than standard LED strobe lights
5. Die-cast aluminum housing for maximum heat dissipation
6. IP68 Water resistant
7. Hard coated flood optic polycarbonate lens
8. Independently control turn signal light, brake / running light, reverse light and 8 strobe patterns
9. Two types of wire harnesses with Power on/off switch (strobe controller) are included
10. Angle adjustable side ends mount brackets included
Strobe Instructions:
Wire Connection:
1) 4-Colors Wire Harness:
Red to brake, white to reverse, black & blue to turn signal;
2) Wire Harness with in-line dual switch:
Black to negative, red to positive.
Light Function:
3) Instruction for In-line dual switch:
? Press the ??-??/??o” to turn ON/OFF.Function momentary.
? Press the ?????? for 3 seconds to change the strobe light patterns.
? Amber/Red/Blue strobe patterns include 1 solid, 8 flash strobe lights.
Package Include:
1x 30″Inch Chasing Light Bar
1x wire harness with in-line dual switch
1x 3Pin extension cable
1x multifunction wire
1x Mounting Brackets&screws
1x Instruction
