Golf Cart Brake Maintenance kit fit EZGO TXT PDS 1997-Up electric models(DOES NOT FIT GAS MODELS);
4 Short Brake Shoe Pads , Replaces OEM # 70794G01, 70795G01, 27943G01, 27944G01, 27945G01;??If your original brake shoes are 2 Short (17T) and 2 Long (17L), do not buy this one??
Rear brake hub drums with 24 tooth star spline, central hole is 0.8 inch/3/4 Inch ,Only Fits 1982-Up EZGO Electric Models (Replace OEM# 19186G1 , PLS confirm before purchase);
Warm tips: Brake Hub spline and Rear Axle Shaft Spline should be matched tight. When one of them wears out, both of them should be replaced at the same time. Otherwise the hub spline will strip soon.
Kindly Note: Please carefully check your own drum’s Size & OEM Part NO before purchase, our hub drum center diameter is 0.8″ small hole with 24-teeth spline(only fit Electric cart ); If you need 1″ large center hole brake hubs for Gas carts ,pls search ASIN: B0993731K3 in our store.
The benefit of tuning up your golf cart includes improved performance, economy and longevity.
This Maintenance Kits include: Brake Shoe Pads (4pcs for 2 rear wheels) and Brake Drums (2pcs).
4 Short Brake Shoe Pads :
For E-Z-Go TXT and Medalist G&E 1997 up, Workhorse 1996 up; Also for electric cars heavy weight model year 1996 and older;
Replace OEM # 27943G01 ,27944G01, 27945G01, 70794G01, 70795G01.
(Reminder: Pls check OEM Part No. before purchase! If your original brake shoes are 2 Short(17T) and 2 Long(17L),then do not buy this ones,they will unfit. )
Brake Drums
(Only fits EZGO Electric carts, DOES NOT FIT Gas carts)
The Brake Drum/Hub Assembly has a 3/4-Inch ( 0.8″ ) center hole with a 24-tooth star spline, Replace OEM# 19186G1 (pls firstly check your own drum’s Diameter and OEM Number ,in case it’s small or big for your axles);
This hub/drum will NOT operate with a keyed axle/hub interface;
The drum is held in place by a castellated nut (5/8-Inch x 18tpi) and a thick (.118-Inch) flat washer.
Reminder: If the connected Axle Shaft has also worn out,you have to replace them both (brake drums and axle shaft). Our axle shaft ASINS: B085TCRM62, B087CNXDQW (click following Hyperlink to buy).
Front Wheel Hub Assembly
Rear Axle Shaft
Golf Cart Brake Assembly
Brake Hub Drum Assembly
Brake Shoes & Brake Spring Kit
Brake Spring Kit
Fit Models
EZGO PDS&TXT/Medalist G&E 2001-Up
EZGO TXT 1994 up
EZGO PDS&TXT RXV&Medalist
EZGO TXT 4 Cycle Gas 1991-Up
EZGO TXT and Yamaha
EZGO Medalist/TXT 91 UP
