Front Left And Right CV Axles For Suzuki Eiger Auto 4×4 LT-A400FC 2005-2007

Premium Quality Replacement Part
Front Left And Right CV AxlesFor Suzuki Models:Eiger Auto 4×4 LT-A400FC 2005-2007Order Includes:
1x Front Left CV Axle : 54902-38F23, 54902-38F10, 54902-38F20, 54902-38F22
Length : 514.35 mm | 20.25 ”
Spline A Length : 51 mm | 2.0 ”
Spline A Boot Width : 73.2 mm | 2.88 ”
Spline A – 20 Tooth
Spline B Length : 28.51 mm | 1.12 ”
Spline B Boot Width : 71 mm | 2.79
Spline B – 20 Tooth
1x Front Right CV Axle : 54901-38F23, 54901-38F10, 54901-38F20, 54901-38F22
Length : 563.9 mm
Spline A Length : 51 mm | 2.01 ”
Spline A Boot Width : 73.1 mm | 2.87 ”
Spline A – 20 Tooth
Spline B Length : 28.5 mm | 1.12 ”
Spline B Boot Width : 70.2 mm | 2.76 ”
Spline B – 20 Tooth
**
