Weight 34.6 lbs
Height 4.7 in
Width 9.4 in
Length 28 in
ABS Ring Included Yes
Axle Features ABS
Axle Nut Hex Size 1.18 in / 30 mm
Axle Nut Included Yes
Axle Nut Locking Type Open Groove
Axle Nut Thread Size M22 x 1.5
Boot Color Black
Cotter Pin Included No
Drive Type FWD
Fitment Type Direct Replacement
Grease Type Molybdenum Disulfide Lithium Grease
Hardware Included No
Hazardous Material No
Inboard Clip Included Snap Ring
Input Shaft Connection Style Spline
ISO Specification ISO 16949
Items Included N/A
Number of Inboard Splines 20 Teeth
Number of Outboard Splines 26 Teeth
Output Shaft Connection Style Spline
Shaft Material 40CR
Surface Finish Black Coating
Transmission Type Manual
