TrakMotive Front CV Axle Shaft Set for 2007-2020 Toyota Tundra (KIT717)
Includes Front Left & Front Right
Fitment Chart:
Years Make Model Drive Type Notes
2007-2020 Toyota Tundra 4WD Not for use on lifted vehicles
Specifications:
Part Category: CV Axle Shaft
Manufacturer Part Number: Kit-717
Vehicle Position: Front Left, Front Right
Placement on Vehicle: Front
Label: CV Axle Shaft
Product Type: Factory Replacement
Type: CV Axle Shaft
Abs Tone Ring Included: No
Axle Nut Head Type: Hex
Axle Nut Height (in): 3/4
Axle Nut Height (mm): 18.6
Axle Nut Hex Size (in): 1 1/2
Axle Nut Hex Size (mm): 38.8
Axle Nut Included: Yes
Axle Nut Length (in): 1 3/4
Axle Nut Length (mm): 44.5
Axle Nut Locking Type: Standard
Axle Nut Thread Size: M32*1.5
Boot Material: Neoprene
Inboard Joint Type: Male
Inboard Shaft Connection Style: Male
New Or Remanufactured: New
Number Of Inboard Splines: 34
Number Of Outboard Splines: 36
Outboard Joint Type: Conventional
Outboard Shaft Connection Style: Conventional
Overall Compressed Length (in): 27.76
Overall Compressed Length (mm): 705
Interchange Part Number: 40751108 434300C020 434300C040 60-5252 60-5252HD 600N 66-5252
Replaces Part Numbers: 66-5252HD 80-6341 AX-6323 MP5252 TO-2230 TO-8-8673 TO-8250
Replacement Part Numbers: TO10035
