Description:
Automatic Balanced Upgraded Billet Compressor Wheel 9+0 blades + Upgrade Rebuild Kit for Ford 7.3L Powerstroke F-Series GTP38 TP38 Turbo Charger
Application
One Repair Kit with upgraded 360?? thrust bearing system and Stepped gap piston ring, exactly as the shown pictures.
1.Stepped Gap Ring eliminates Oil Leakage Problem.
2.360 degree Trust Bearing for performance applications.
One Upgrade 9+0 Billet Compressor wheel
For Turbo:GTP38 /TP38
For Vehicle:for 94~03 FORD 7.3L POWERSTROKE
Compressor Wheel Specifications
Inducer Dia.:59.87 mm
Exducer Dia.:80.07 mm
Trim: 56
Extend Tapered Tip Exducer dia : 83.88 mm
Tip Height: 6.33 mm
Super Back Height: 4.94 mm
Bore: 6.35 mm
Blade:9+0
Rotation:Reverse
Bore Type:Threaded-1/4-28G-RHT
Advantage of Billet compressor wheel
10%+ Gain in flow over traditional GT compressor wheel desighs
10%+ Higher pressure ration compared to traditional compressor wheel designs
Forged,fully machined billet wheels for expedited release
Rebuild kit Specifications
Item Part Description Quantity
1 360 Degree Thrust Bearing 1
2 360 Degree Thrust Collar 1
3 360 Degree Thrust Spacer 1
4 Journal Bearing, Improved Design 2
5 Turbine End Step Gap Oil Seal Ring 1
6 Compressor End Seal Ring 1
7 Bolt, M8x1.25, Grade 12.9 13
8 O-Ring, Square, Bearing Housing 1
9 O-Ring, Compressor Housing 2
10 O-Ring, Sealplate 1
11 O-Ring, Pedestal 1
12 Bearing Spacer 1
