Features:
One pair universal fit ATV shocks. ( 1 x Left + 1 x right)
Shock strength is adjustable. Easy to install.
Fit on most 150cc~750cc Sport bikes, like for HONDA for Suzuki for Yamaha for Kawasaki and Dirt Bikes, Go-kart, ATV, UTV and Moped Quad.
Fit bikes with shocks of 375mm eye to eye distance. (Please confirm the size and the end type before placing order)
Packaged Included: 1 Pair 375MM Air Shock Absorbers
Specification:
Type:Shock Absorber
Working Stroke: 68mm
Spring Stiffness: 110 kg
Maximum load: 300 kg (??660 lbs).
Total Length: 400mm (15.75″)
Length of Eye to Eye Core: 375mm (14.75″)
Eye Diameter(with bushing): 12mm
Eye Diameter(with bushing removed): 16mm.
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa.
Eye Thickness: 21mm
Eye Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 8mm
Spring Width: 60mm.
Fitting manual is not included. instal by qualified mechanic is recommended.
Material: Solid Steel+Aluminium Alloy.
Condition: Brand new/Never used.
Installation Type: Eye to Eye.
Color: As picture show.
Fitment:
Fit for Yamaha Banshee 350 (YFZ350) 1987-2006
For 2006 Yamaha Banshee 350 YFZ350
For 2006 Yamaha Banshee 350 YFZ350SE Special Edition
For 2006 Yamaha Banshee 350 YFZ350SP 50th Anniversary Edition
For 2005 Yamaha Banshee 350 YFZ350
For 2005 Yamaha Banshee 350 YFZ350SE Special Edition
For 2004 Yamaha Banshee 350 YFZ350
For 2004 Yamaha Banshee 350 YFZ350LE Limited Edition
For 2003 Yamaha Banshee 350 YFZ350
For 2002 Yamaha Banshee 350 YFZ350
For 2001 Yamaha Banshee 350 YFZ350
For 2000 Yamaha Banshee 350 YFZ350
For 1999 Yamaha Banshee 350 YFZ350
For 1998 Yamaha Banshee 350 YFZ350
For 1997 Yamaha Banshee 350 YFZ350
For 1996 Yamaha Banshee 350 YFZ350
For 1995 Yamaha Banshee 350 YFZ350
For 1994 Yamaha Banshee 350 YFZ350
For 1993 Yamaha Banshee 350 YFZ350
For 1992 Yamaha Banshee 350 YFZ350
For 1991 Yamaha Banshee 350 YFZ350
For 1990 Yamaha Banshee 350 YFZ350
For 1989 Yamaha Banshee 350 YFZ350
For 1988 Yamaha Banshee 350 YFZ350
For 1987 Yamaha Banshee 350 YFZ350
Note:
Please check the size measurement chart carefully before purchasing
Please allow 1-2mm for variance due to manual measurement
Installation instruction is not included
If you have questions, please feel free to contact us, thank you!
Package Included:
1 Pair (Left & Right ) Air Front Shocks Absorbers (As the picture)
