540mm Disc Brake Front Fork Triple Clamp Bar Riser for 50cc 70cc 110cc Pit Dirt Bike
540mm Disc Brake Front Fork Triple Clamp Bar Riser for 50cc 70cc 110cc Pit Dirt Bike
540mm Disc Brake Front Fork Triple Clamp Bar Riser for 50cc 70cc 110cc Pit Dirt Bike
Brand New 540mm Disc Brake Front Fork Triple Clamp Bar Riser 50cc 70cc 110cc PIT Dirt Bike
TOTAL LENGTH (from leg top to wheel axle centre) approx 540mm
DISTANCE BETWEEN UPPER AND LOWER CLAMP approx 145mm
DIAMETER OF FORK LEG FOR THE CLAMP approx 28mm
DIAMETER OF THE HEAD STEM BOLT approx 23.35mm
DIAMETER OF THE AXLE HOLE approx 12mm
INNER DIAMETER OF THE BAR RISER approx 22mm
DISTANCE BETWEEN THE FRONT CALIPER MOUNTING HOLES (bolt centre to bolt centre)
