3.5K TK Trailer Axle ?C 3500 lb Idler 5-Lug Dexter-Compatible Axle ?C 61″ Hubface, 46″ Spring Center ?C 5×5 Bolt Pattern

61″ Hubface 46″ Spring Center / 5×5 Bolt Pattern | Specs: 3,500 lbs Idler Trailer Axle (Capacity 3.5K), 5 Lug, Tube: 2 3/8″
Internal Components: 3.5k (3500 lb Capacity) Bearing Kit, 3.5k TK Axle Hub – 5 lug Brake, 3.5k TK Axle Beam – 3.5k Tube, 3.5k TK Axle Studs – 1/2″
How to Measure Your Idler Trailer Axle – Hubface: Measure from one face of hub (where the studs start coming out of hub) to the face of hub on opposite side. Spring Center: Measure from center of one spring seat, to the center of spring seat on opposite side (see image in gallery for more details).
High Strength Straight Steel Axle Tube Construction – Ensures even tire wear and a better highway experience | Underslung – Axle is welded with spring seats on the bottom. Allows for lower ride height. For optimal usage, use with double eye springs.
Replaces Dexter, AL-KO, Hayes, and Lippert Axles. Design for use on Light Duty Trailers: Utility, Boat, Car Haulers, ATV, Lawn & Landscape, Motorcycle, BBQ Pit, Cargo, Enclosed, RV & More
