2.5″ 63mm Universal Intercooler Pipe Piping Kit + BOV Turbo Blow Off Valve Kit

SKU JQG.04192 03CSG003UBK Category Tags ,

Application:
2.5″ 63mm Universal Aluminium Intercooler Pipe Piping Kit + BOV Turbo Blow Off Valve Kit
Include:
Straight Silicon Hose X6
90 degree Silicone hose X2
T-Clamps X16
90 degree alloy pipes X2
45 degree alloy pipes X2
Straight alloy pipes X2
180 degrees U-bent alloy pipes X2
1 x Flange Pipe
1 x Blow Off Valve
Vacuum Hose And Accessories
Description:
Pipe Thickness: 1.8 mm
Pipe length:18″ (450mm)
for Many Turbo Intercooler Applications
Turbo Blow Off Valve Kit:
The Blow-Off valve (BOV) is a pressure relief device on the intake tract to prevent the turbos compressor from going into surge.
When the throttle is closed rapidly, the airflow is quickly reduced, causing flow instability and pressure fluctuations.
Surge can eventually lead to thrust bearing failure due to the high loads associated with it.
Blow-Off valves use a combination of manifold pressure signal and spring force to detect when the throttle is closed.
When the throttle is closed rapidly, the BOV vents boost in the intake tract to atmosphere to relieve the pressure, helping to eliminate surge.
Horn with 8 Discharge Ports That Releases a Unique Discharge Sound
Dual Spring System Promoted Response and Allows for High Boost Pressures
Holds Up to 30 PSI Boost Pressure
2 Bolt Mounting Design
