Applications
for BRIGGS & STRATTON 12HP MOTORS
for Cub Cadet 1015 1988 – 1991
for Cub Cadet 1020 1988 – 1991
for Cub Cadet 1105 1985 – 1986
for Cub Cadet 111 1978 – 1979
for Cub Cadet 1110 1985 – 1986
for John Deere 111 1979 – 1985
for John Deere 111H 1982 – 1984
for John Deere L118 –
for Toro 11-32 1978 – 1997
for Toro 11-38 1986 – 1987
for Toro 212-H 1989 – 1991
for Toro 825 1991
for Toro LT12.5G 1995
for Toro Sand Pro5000 1992 – 1993
OEM & Part Number:
for ARROWHEAD: SBS0004
for BRIGGS & STRATTON: 394943, 399169, 490420, 494148,
494198, 494990, 497401, 499521, 499529, 691262, 795121
for CARGO : 112563
for CUB CADET: BS-399169, BS-499521
for GENERAC: 075255, 75255, 75255-A
for J & N: 410-22005, 410-22015
for JOHN DEERE: AM106883, AM38136, AM39285,
LG490420, LG497401, LG499521, LG691262, MIA11175, SE501860
for LESTER: 5746, 5778
for NSA: STR-1005A
for TORO: 78-4340
for TUCKER ROCKY: 49-5790
for WAI: 2-2191
Specifications
Voltage : 12V
Rotation : CCW
Starter Type : PMDD
Number of Teeth : 16
Gear OD : 1.598in / 40.6mm
Mtg Ear 1 Hole : 8.0mm Unthreaded
Mtg Ear 2 Hole : 8.0mm Unthreaded
Mtg Ear 3 Hole : 8.0mm Unthreaded
Notes : 4.25″/108mm Long Field Case
Weight : 5.68 lbs / 2.58 kg
Mounting bolt spacing : approx 58.5mm
